QXR-QXD-QXL-JVR-JVA-QXC-KVA-JVB全系列参数明细表展示给大家

     时间：2017-09-17 17:44    点击：
COMPRESSOR PERFORMANCE PARAMETERS: Refrigeran P ower supply Model cc/rev Cooling Capacity Input Power（W） COP Capacitor （F/450VAC） Height (mm） W Btu/h R22 1PH 220V/50Hz QHR-10E 9.6 1550 5270 530 2.92 20 180 QHR-13E 13.5 2250 7650 750 3


COMPRESSOR PERFORMANCE PARAMETERS:



Refrigeran Power supply Model cc/rev  Cooling Capacity   Input Power（W） COP Capacitor      （µF/450V•AC） Height (mm）
W Btu/h
R22   1PH 220V/50Hz  QHR-10E   9.6 1550 5270 530 2.92 20 180
QHR-13E  13.5 2250 7650 750 3.0 25 180
QHR-16E  16.4 2800 9520 950 2.95 25 180
 QHR-19E   19.2 3250 11050 1120 2.90 30 195
 QHR-23E   23.5 3920 13328 1360 2.88 35 195
QHR-30E  30.7 5100 17340 1800 2.83 50 195
R407C  1PH          220V-240V/50Hz QHC-10K  9.6 1580 5372 540 2.93 15 180
QHC-13K  13.5 2260 7684 780 2.90 20 180
QHC-16K  16.4 2760 9384 930 2.97 25 180
QHC-19K  19.6 3200 10880 1100 2.91 30 195
QHC-23K  23.5 3830 13022 1280 2.99 35 195
QHC-30K  30.7 5080 17272 1800 2.83 50 195
 QHC-36K   35.7 5960 20264 2090 2.85 50 195
 1PH 220V-240V/60Hz KFC113Y  11.3 2280 7752 780 2.92 20 165
R410A 1PH 115V/60Hz KFA092T  9.2 2760 9384 950 2.9 60 165
KFA113T  11.3 3360 11424 1160 2.90 60 165
SFA138T  13.5 3920 13328 1350 2.90 90 175
1PH 220V-240V/50Hz JFA058K 5.8 1510 5134 530 2.85 20 150
JFA065K 6.5 1650 5610 580 2.85 20 150
KFA096K  9.6 2280 7752 800 2.85 25 165
KFA102K  10.2 2440 8296 830 2.94 25 165
SFA138K  13.5 3190 10846 1120 2.85 30 195
R134a 1PH     220V-240V/50Hz JFB092K  9.2 1000 3400 390 2.56 15 145
JFB106K 10.6 1160 3944 410 2.83 20 128
1PH 115V/60Hz SFB236T  23.6 3250 11050 1100 2.95 50 165



COMPRESSORS TESTING CONDITIONS :

TESTING POWER SUPPLY EVAPORATING TEMPRETURE. CONDENSING TEMPRETURE. SUB-COOLING TEMP. AMBIENT TEMPRETURE. SUCTION TEMPRETURE
220V～50Hz 7.2℃ 54.4℃ 46.1℃ 35℃  35℃

NOTE：PRODUCT PERFORMANCE PARAMETERS ARE SUBJECT TO CHANGES WITH IMPROVEMENT OF COMPRESSORS WITHOUT NOTICE




COMPRESSOR PERFORMANCE PARAMETERS:

REFRIGERANT MODEL POWER SUPPLY CYLINDER
VOLUME
（cm³）		 NOMINAL
CAPACITY		 INPUT COP Capacitor
uf/450VAC
W Btu/h POWER(W) (W/W)
VERTICAL R410A JVA075T 115V/60HZ 7.5 2060 7025 725 2.80 40
JVA075K 220-240V/50HZ 1660 5661 615 2.80 20
JVA090T 115V/60HZ 8.9 2440 8320 870 2.80 40
JVA090K 220-240V/50HZ 1970 6718 700 2.80 20
R134a JVB075K* 220-240V/50HZ 7.5 870 2967 295 2.95 15
JVB092K* 9.2 1060 3615 360 2.95 15
JVB132K* 13.2 1530 5217 520 2.95 20
JVB075T* 115V/60HZ 7.5 1050 3581 350 3.00 15
JVB092T* 9.2 1250 4262 415 3.00 15
JVB132T* 13.2 1850 6309 615 3.00 20
NOTE: In developing.(The displacement could be adjusted or developed as your requirement)
TEST CONDITIONS:
APPLICATION AMBIENT TEMP. EVAP. TEMP. RETURN GAS TEMP. SUBCOOLING TEMP. CONDENSING TEMP.
HIGH TEMP 35℃ 7.2℃ 35℃ 46.1℃ 54.4℃

Previous：R134a R22 Heat pump water heater R134a Clothes dryer compressor

Next：DC VARIABLE SPEED COMPRESSOR


COMPRESSOR PERFORMANCE PARAMETERS:



Refrigerant

Power

Model

Control Model

排量

cc/rev

调速范围

(rpm)

额定转速

(rpm)

 制冷量

输入功率

Input

Power（W）

COP

值

Height

(mm）
W Btu/h

Vertical

 R134a DC12V JVB075Z12  BYC(D)12-400-4 7.5 2500-3700 3300 850 2890  340 2.50 228
DC24V JVB075Z24  BYC(D)24-400-4 7.5 2500-4500 3300 920 3128  340 2.7 228
KVB135Z24  BYC(D)24-600-2 13.5 2500-4500 3300 1780 6052  580 3.07 269
DC48V JVB058Z48  BYC(D)48-300-4 5.8 2100-5400 3600 840 2856  255 3.3 190
KVB135Z48  BYC(D)48-600-2 13.5 2500-4500 3300 1780 6052  560 3.17 269
SVB208Z48  BYC(Z)48-1240-2 20.8 2500-4200 3600 3010 10234  970 3.1 271.5

Horizontal

 R134a DC12V HB075Z12  BYC(D)12-400-4 7.5 2500-3700 3300 850 2890  340 2.50 136.5
  JFSB116Z12 / 11.6 1800-4500 3000 1000 3400  400 2.5 145
DC24V HB075Z24  BYC(D)24-400-4 7.5 2500-4500 3300 920 3128  340 2.7 136.5
JFSB150Z24  / 15.0 1800-4500 3300 1750 5950  565 3.10 145
KFB135Z24  BYC(D)24-600-2 13.5 2500-4500 3300 1780 6052  570 3.12 169
DC48V JFSB180Z48  / 18.0 1800-4500 3600 2500 8500  770 3.25 106
KFB135Z48  BYC(D)48-600-2 13.5 2500-5000 3300 1780 6052  570 3.12 169
DC60-72V JFSB150Z60  BYC(J)72-700-4 15.0 2500-5000 3600 2100 7140  645 3.25 106
JFSB150Z72 BYC(J)72-700-4 15.0 2500-5000 3600 2100 7140  645 3.25 106
JFSB180Z60 BYC(J)60-700-4 18.0 2500-5000 3600 2500 8500  770 3.25 106
JFSB180Z72 BYC(J)72-700-4 18.0 2500-5000 3600 2500 8500  770 3.25 106
DC312V JFSB150Z312  BYC(J)312-600-4 15.0 1800-5400 3600 2100 7140  635 3.3 106
JFSB180Z312  BYC(J)312-600-4 18.0 2500-5000 3600 2450 8330  765 2.28 106
KFB208Z312  BYC(J)312-1000-3 20.8 2400-4500 4100 3300 11220  1064 3.4 169
R410a 220V/50Hz KFA102Z220  BYC(J)220-1000-3 10.2 2400-4500 4200 3675 12495  1150 3.2 160
KFA113Z220  BYC(J)220-1000-3 11.3 2400-4500 3600 3450 11730  1080 3.2 160
JFSA116Z220  / 11.6 1800-4500 3600 3600 12240  1150 3.2 147
R407c 220V/50Hz KFSA138K / 13.8 / / 3200 10880  1143 2.80 170
KFSC184K / 18.4 / / 3200 10880  1143 2.80 170







COMPRESSORS TESTING CONDITIONS :


EVAPORATING TEMPRETURE  CONDENSING TEMPRETURE. SUB-COOLING TEMP. AMBIENT TEMPRETURE. SUCTION TEMPRETURE.
7.2℃ 54.4℃ 46.1℃ 35℃ 35℃





Previous：R410A、R134a COMPRESSOR

Next：R22 R134a R410A COMPRESSOR




COMPRESSOR PERFORMANCE PARAMETERS:

Refrigerant

Rate

Power

Compressor

 type

Cylinder

 capacity

 cc/rev

Cooling

capacity

input

 power

(W)

 COP

Ru

nCapacitor

 (µF/450V•AC)



Compressor

Height

(mm）
W Btu/h
R407C 1PH  220V-240V/50Hz JVC090K 9.0 1570 5338 500 3.14 20 240
JVC132K 13.2 2290 7786 790 2.90 25 263
QXC-10K 9.6 1580 5372 550 2.87 20 293
QXC-13K 13.5 2260 7684 760 2.97 25 293
QXC-16K 16.4 2760 9384 920 3.0 25 293
QXC-19K 19.2 3200 10880 1060 3.02 30 286
QXC-21K 20.8 3500 11900 1180 2.97 30 307.5
QXC-23K 23.5 3900 13260 1320 2.95 35 307.5
QXC-25K 25.4 4180 14212 1410 2.96 35 307.5
QXC-30K 30.7 5080 17272 1710 2.97 50 316.5
QXC-33K 33.6 5580 18972 1900 2.94 50 316.5
QXC-36K 35.7 5960 20264 2030 2.94 50 316.5
QXC-41K 41.2 6880 23392 2360 2.92 50 359.4
1PH  220V-240V/60Hz JVC075Y 7.5 1500 5100 500 3.0 20 247
JVC132Y 13.2 2600 8840 900 2.89 30 263

R410A 1PH 115V/60Hz JVA090T 9.0 2540 8636 910 2.8 55 250
1PH 220V-240V/50Hz JVA075K 7.5 1870 6358 650 2.9 20 250
JVA086K 8.6 2150 7310 750 2.87 25 250
JVA090K 9.0 2250 7650 790 2.85 20 250
KVA096K 9.6 2280 7752 800 2.85 20 276
KVA113K 11.3 2730 9282 960 2.84 25 276
R134a 1PH 220V-240V/50Hz JVB075K 7.5 830 2822 290 2.87 15 219
JVB092K 9.2 1050 3570 390 2.7 15 219
JVB132K 13.2 1470 4998 500 2.94 20 250
KVB096K 9.6 1100 3740 370 2.95 15 265
KVB135K 13.5 1500 5100 490 3.06 20 265
1PH 115V/60Hz JVB075T 7.5 1050 3570 350 3.0 20 219
JVB092T 9.2 1250 4250 415 3.0 15 250
JVB132T 13.2 1850 6290 615 3.0 20 263
3PH 380V/50Hz JVB132F 13.2 1450 4930 530 2.73 / 264




TEST CONDITIONS:NOTE: In developing.(The displacement could be adjusted or developed as your requirement)



APPLICATION AMBIENT TEMP. EVAP. TEMP. RETURN GAS TEMP. SUBCOOLING TEMP. CONDENSING TEMP.
HIGH TEMP 35℃ 7.2℃ 35℃ 46.1℃ 54.4℃

Previous：DC VARIABLE SPEED COMPRESSOR

Next：R22、R407C compressor


COMPRESSOR PERFORMANCE PARAMETERS:



Refrigerant

Rate

Power

Compressor

 type

Cylinder

capacity

cc/rev

Cooling

capacity

input

power

（W）

 COP

Run

 Capacitor

（µF/450V•AC）

Compressor

Height

(mm）
W Btu/h
R22 1PH 220V/50Hz JVR132E 13.2 2300 7820 750 3.07 25 263
QXR-10E 9.6 1600 5440 550 2.91 20 293
QXR-13E 13.5 2280 7752 740 3.08 25 293
QXR-16E 16.4 2800 9520 910 3.08 25 293
QXR-19E 19.2 3250 11050 1070 3.03 30 286
QXR-21E 20.8 3520 11968 1180 2.98 30 307.5
QXR-23E 23.5 3920 13328 1300 3.02 35 307.5
QXR-25E 25.4 4220 14348 1410 2.99 35 307.5
QXR-30E 30.7 5100 17340 1710 2.98 50 316.5
QXR-33E 33.6 5600 19040 1900 2.95 50 316.5
QXR-36E 35.7 5950 20230 2030 2.93 50 316.5
QXR-41E 41.2 6900 23460 2360 2.93 50 359.4
QXR-44E 44.2 7620 25908 2540 3.0 50 359.4
1PH 220-240V/50Hz JVR075K 7.5 1280 4352 450 2.85 15 219
JVR092K 9.2 1600 5440 520 3.08 20 240
JVR132K 13.2 2300 7820 750 3.07 25 263
KVR192K 19.2 3250 11050 1070 3.03 30 286
KVR208K 20.8 3550 12070 1170 3.03 30 286
1PH 220V/60Hz JVR092Y 9.2 1920 6528 620 3.10 20 250
QXR-13Y 13.5 2730 9282 900 3.03 20 293
QXR-16Y 16.4 3360 11424 1100 3.05 20 293
QXR-19Y 19.2 3900 13260 1280 3.05 25 286
QXR-21Y 20.8 4220 14348 1410 2.99 30 307.5
QXR-25Y 25.4 5060 17204 1720 2.94 35 307.5
QXR-27Y 26.4 5390 18326 1820 2.96 35 314.5
QXR-33Y 33.6 6810 23154 2320 2.94 45 316.5
QXR-36Y 35.7 7300 24820 2500 2.92 50 359.4



COMPRESSOR PERFORMANCE PARAMETERS:
Refrigerant Model Power Supply Cylinder Volume （cm³） Different evaporating temperature corresponding refrigerating capacity W
-40 -30 -23.3 -20 -15 -10 -5
Vertical R22 KXL096ES 4DN 220V/50Hz 9.6 224 397 560 598 737 863 1060
QXL-13E 4DN 220V/50Hz 13.5 260 465 745 800 1050 1365 1748
QXL-16E 4DN 220V/50Hz 16.4 385 560 920 1020 1300 1670 2150
QXL-19E 4DN 220V/50Hz 19.2 450 650 1010 1200 1530 1960 2490
QXL-23E 4DN 220V/50Hz 23.5 560 810 1230 1380 1820 2430 3142
QXL-30E 4DN 220V/50Hz 30.7 730 1050 1690 2020 2430 3180 4000
QXL-36E 4DN 220V/50Hz 35.7 850 1250 1886 2304 2860 3650 4576
QXL-41E 5DS 220V/50Hz 41.2 980 1440 2300 2650 3300 4200 5279
R404A KXD096KS 4DN 220-240V/50Hz 9.6 314 470 570 723 907 1100 1328
QXD-13K 4DN 220-240V/50Hz 13.5 430 650 845 995 1230 1506 1816
QXD-16K 4DN 220-240V/50Hz 16.4 539 780 1046 1235 1515 1840 2210
QXD-19K 4DN 220-240V/50Hz 19.2 630 920 1230 1450 1780 2165 2605
QXD-23K 4DN 220-240V/50Hz 23.5 785 1130 1516 1790 2130 2645 3170
QXD-30K 4DN 220-240V/50Hz 30.7 1023 1480 2100 2320 2832 3500 4341
QXD-36K 4DN 220-240V/50Hz 35.7 1200 1750 2303 2720 3315 4020 4840
QXD-41K 5DS 220-240V/50Hz 41.2 1380 2020 2650 3140 3825 4640 5600
Horizontal R22 QHL-13E 8A 220V/50Hz 13.5 260 465 745 800 1050 1365 1748
QHL-16E 8A 220V/50Hz 16.4 385 560 924 1020 1300 1670 2150
QHL-23E 8A 220V/50Hz 23.5 560 810 1234 1380 1820 2430 3142
QHL-30E 9C 220V/50Hz 30.7 730 1050 1694 2020 2430 3180 4000
QHL-36E 9C 220V/50Hz 35.7 850 1250 1886 2304 2860 3650 4576
THR357F 380V/50HZ 35.7 850 1250 1886 2304 2860 3650 4576
THR412F 380V/50HZ 41.2 980 1440 2300 2650 3300 4200 5279
R404A QHD-13K 8A 220-240V/50Hz 13.5 430 650 845 995 1230 1506 1816
QHD-16K 8A 220-240V/50Hz 16.4 539 780 1046 1235 1515 1840 2210
QHD-23K 8A 220-240V/50Hz 23.5 785 1130 1516 1790 2180 2645 3170
QHD-30K 9C 220-240V/50Hz 30.7 1023 1480 2100 2320 2832 3500 4341
QHD-36K 9C 220-240V/50Hz 35.7 1200 1750 2303 2720 3315 4020 4840
THD357F 380V/50HZ 35.7 1200 1750 2303 2720 3315 4020 4840
THD412F 380V/50HZ 41.2 1380 2020 2650 3140 3825 4640 5600
KHD135YS 8A 220V/60Hz 13.5 560 845 1100 1295 1600 1950 2350
KHD164YS 8A 220V/60Hz 16.4 710 1030 1380 1625 2000 2415 2875
SHD236YS 8A 220V/60Hz 23.6 960 1380 1860 2195 2675 3240 3900
THD307YS 9C 220V/60Hz 30.7 1235 1785 2350 2795 3415 4215 5100
THD357YS 9C 220V/60Hz 35.7 1355 1980 2600 3075 3745 4545 5475
NOTE: In developing.(The displacement could be adjusted or developed as your requirement)
TEST CONDITIONS
APPLICATION AMBIENT TEMP. TESTING POWER SUPPLY RETURN GAS TEMP. SUBCOOLING TEMP. CONDENSING TEMP. TESTING WIND SPEED
HIGH TEMP 32.2℃ 220V~50Hz 32.2℃ 32.2℃ 54.4℃ 2m/s
