NL7.3MF NL8.4MF NL10MF原装正品丹佛斯思科普冰箱冷柜压缩机主流

     时间:2020-11-03 10:41    点击:
NL7.3MF NL8.4MF NL10MF全新原装正品丹佛斯思科普冰箱冷柜压缩机
NL7.3MF全新
我们专业销售压缩机,这款NL7.3MF,NL8.4MF,NL10MF压缩机寿命是5年左右, 具体要你空调其他相关配件质量一起命才能长久。
下面是这三款压缩机的详细参数,

NL7.3MF
Standard Compressor
R134a
220-240V 50Hz & 208-230V 60Hz
General
Code number 105G6772
Approvals EN 60335-2-34, UL984
Compressors on pallet 80
Application
Application MBP
Frequency Hz 50 60
Evaporating temperature °C -20 to 15 -35 to 7.2
Voltage range V 187 - 254 198 - 254
Max. condensing temperature continuous (short) °C 60 (70) 60 (70)
Max. winding temperature continuous (short) °C 125 (135) 125 (135)
Cooling requirements
Frequency Hz 50 60
Application LBP MBP HBP LBP MBP HBP
32°C – F 1 F 1 F 1 F 1 –
38°C – F 1 F 1 F 1 F 1 –
43°C – F 1 F 1 F 1 F 1 –
Remarks on application:  F 2 for 230-240V 50Hz nominal below -12°C evaporating temp.
CSIR strongly recommended for 60Hz
Motor
Motor type RSIR/CSIR
LRA (rated after 4 sec. UL984), HST | LST A 11.3 8.8
Cut in Current, HST | LST A 11.3 12.9
Resistance, main | start winding (25°C) Ω 8.3 17.0
Design
Displacement cm 3 7.27
Oil quantity (type) cm 3 320 (polyolester)
Maximum refrigerant charge g 600
Free gas volume in compressor cm 3 2360
Weight without electrical equipment kg 10.5
Dimensions
Height mm A 197
B 191
B1 –
B2 –
Suction connector location/I.D. mm | angle C 8.2 | 15°
material | comment Copper | Rubber plug
Process connector location/I.D. mm | angle D 6.2 | 25°
material | comment Copper | Rubber plug
Discharge connector location/I.D. mm | angle E 6.2 | 35°
material | comment Copper | Rubber plug
Oil cooler connector location/I.D. mm | angle F –
material | comment  –
Connector tolerance I.D. mm ±0.09
NL8.4MF
Standard Compressor
R134a
220-240V 50Hz & 208-230V 60Hz
General
Code number 105G6877
Approvals EN 60335-2-34, UL984
Compressors on pallet 80
Application
Application MBP
Frequency Hz 50 60
Evaporating temperature °C -20 to 15 -35 to 7.2
Voltage range V 187 - 254 198 - 254
Max. condensing temperature continuous (short) °C 60 (70) 60 (70)
Max. winding temperature continuous (short) °C 125 (135) 125 (135)
NL10MF
Standard Compressor
R134a
220-240V 50Hz & 208-230V 60Hz
General
Code number 105G6886
Approvals EN 60335-2-34, UL984
Compressors on pallet 80
Application
Application MBP
Frequency Hz 50 60
Evaporating temperature °C -20 to 15 -35 to 7.2
Voltage range V 187 - 254 198 - 254
Max. condensing temperature continuous (short) °C 60 (70) 60 (70)
Max. winding temperature continuous (short) °C 125 (135) 125 (135)
Cooling requirements
Frequency Hz 50 60
Application LBP MBP HBP LBP MBP HBP
32°C – F 1 F 1 F 1 F 1 –
38°C – F 1 F 1 F 1 F 1 –
43°C – F 1 F 1 F 1 F 1 –
Remarks on application:  F 2 for 230-240V 50Hz nominal below -12°C evaporating temp.
CSIR strongly recommended for 60Hz
Motor
Motor type RSIR/CSIR
LRA (rated after 4 sec. UL984), HST | LST A 16.1 13.1
Cut in Current, HST | LST A 16.1 17.1
Resistance, main | start winding (25°C) Ω 6.1 17.5
Design
Displacement cm 3 10.10
Oil quantity (type) cm 3 320 (polyolester)
Maximum refrigerant charge g 600
Free gas volume in compressor cm 3 2360
Weight without electrical equipment kg 10.5
Dimensions
Height mm A 203
B 197
B1 –
B2 –
Suction connector location/I.D. mm | angle C 9.7 | 15°
material | comment Copper | Rubber plug
Process connector location/I.D. mm | angle D 6.5 | 25°
material | comment Copper | Rubber plug
Discharge connector location/I.D. mm | angle E 6.5 | 35°
material | comment Copper | Rubber plug
Oil cooler connector location/I.D. mm | angle F –
material | comment  –
Connector tolerance I.D. mm ±0.09
供大家参考 假如空调有其它故障管道系统脏堵或散热系统不良的话是不能估计使用日期的.同行的维修师傅们知道的.如果本身你空调系统有问题,或是安装不到位 ,那你装多少台上去都没有用,还是一样不行的!
